CDL High Pressure Vertical Multistage Centrifugal Pump for Fire Fighting System

• DN Suction size: 25-100 mm (1"-4")
• DN Discharge size: 25-100 mm (1"-4")
• Flow Capacity Range: 0.6-110m3/h
• Head/Pressure Range: 6-300m
• Power Range: 0.37-45kw

The CLDF vertical multistage pump (pump body, shaft,impeller, etc.) are made of stainless steel, which is resistant to wear and has a long service life. It is used as a stabilized pump in the fire pump system to maintain the pressure of the fire line. The pump is suitable for high temperature water supply, hot water circulation, boiler water supply, fire pressurization, high-rise building water supply and water treatment, and water purification.

• CDL/ CDLF is a kind of vertical non-self priming multistage centrifugal pump, which is driven by a standard electric motor.The inlet and outlet are located at the pump bottom at the same level.
• CDL/ CDLF takes the advantages of outstanding design of hydraulic model, high efficiency and sound energy conservation. The inside impeller, casing and other main components are all stainless steel.
• CDL/ CDLF is a kind of vertical non-self priming multistage centrifugal pump, which is driven by a standard electric motor. The motor output shaft directly connects with the pump shaft through a coupling. The pressure-resistant cylinder and flow passage components are fixed between pump head and inlet & outlet section with stay bolts.
• The electric pump is coupled with YE3 high efficient motor with protection IP55 class F, anti-corrosive coating pump case, quality NSK bearings, and wear resistance mechanical seal.
• Water treatment: Ultrafiltration system, reverse osmosis system, distillation system, separator, swimming pool.Irrigation: Farmland irrigation, spray irrigation, dripping irrigation.
